We provide one-stop manufacturing service on part analyze, mold design, mold manufacturing, mold test, sample inspection, mold inspection to mold shipping, we make various mold that the biggest mold weight up to 30 tons and part tolerance up to 0.015mm.
Every mold is designed in 2D assembly and detailed component drawing as well as 3D assembly drawing, providing complete 2D & 3D drawings for tooling and manufacturing and ensuring proper assembly of all components.
Using high speed & high precision CNC, EDM, Wire cut machine to make mold components, most of mold component without fitting, all dimension make by machining, also we use CMM inspect component to double checking to ensure every dimension on every components are correct, so we canguaranteeour mold quality and mold lead time.
Mold manufacturing capacities: | |||
Mold base standard | LKM | FUTABA | |
EQUI HASCO | EQUI DME | ||
Mold base steel | 1.1730 | S50C | |
1.1738 | P20 | ||
1.2711 | Or clients request | ||
Mold component standard | DAIDO | EQUI HASCO | |
EQUI DME | or clients request | ||
Mold steel | 1.2738 | 1.2711 | |
1.2343 /1.2344 | 1.2083/1.2083H | ||
738 / 738H | 718/718H | ||
1.8407 | NAK80 | ||
S136/S136H | H13 | ||
DH31-S | DC53 | ||
PAT 868 | Or clients request | ||
Gate type | Cold runner | Hot runner | |
Hot runner systerm | MOLD-MASTERS | INCOE | |
HUSKY | SYNVENTIVE | ||
DME | HASCO | ||
YUDO | Or clients request | ||
Mold structure type | 3 plates mold | Hot runner system mold | |
Unscrew mold | Gas-assisted mold | ||
Over molding mold | 2K mold | ||
Insert mold | Multi cavities mold | ||
Part Surface | Polish | Mirror polishing | |
Texture | Or clients request | ||
Serve Industry field | Automotive | Agricultural | |
Medical | Aerospace | ||
Security &Protection | Industrial | ||
Consumer | Packaging | ||
Lighting | Architectural | ||
Electronic | Household appliances | ||
Furniture | Office appliances | ||
Telecom | Military | ||
Plastic material | As clients request | ||
Industry standard | ISO 9001-2008 | TS16949 | |
Advantages | Shorter delivery time | Professional team | |
Competitive price | Good communication | ||
Tight tolerance | Good quality control | ||
File format | 2D format | 3D format | |
DWG | STEP | ||
IGES | |||
DXF | X_T | ||
Packaging | Wood case / pallet | ||
Shipping | By air / By sea | ||
FOB ShenZhen |
